| Brand Name : | Johnbull |
| Certification : | CE |
| Model Number : | 4LBZ-110 |
| Price : | usd1000-20000.00/set |
| Delivery Time : | within 10-45 days after receipt of payment |
| Payment Terms : | 30% deposit by TT and balance to be paid before shipment by TT |
| Supply Ability : | as per order |
Self Walking Crawler Half-feeding Combine Harvester 4LBZ-110 with 20HP diesel Engine
Machine Description:
1. 4LBZ-110 combine harvester is a national patented product with many patented technologies.
It has passed the authentication of the scientific research achievement by the National Bureau of
Agricultural Machinery, and has obtained the agricultural machinery promotion license, and is a national
major support project of agricultural machinery.
2. It’s convenient in operating, it may be operated by both male and female easily. It’s small in size, light in
weight, easy in travel control, flexible in turning. It’s simple in disassembling and convenient for
maintenance.
3. With high adaptability , it can be operated in both dry fields and paddy fields, and is suitable for
harvesting in the large fields in plain areas and in the small fields in hill areas.
4. It’s strong in power and grade ability, it can pass the ridges conveniently and flexibly.
5. It’s of compact structure, threshes in two times. The first threshing integrates threshing and conveying,
and the second threshing integrates threshing and sundries removal. The overall threshing effect is good.
Mini half-feeding is the current advanced harvesting technology in the world. It’s of high harvesting
efficiency and low fuel consumption, and ensures the recycling of straws.
Machine Parameters:
| Name | Half-feeding- self-propelling Rice Combine Harvester | |
| Model | 4LBZ-110 | |
| Structure Form | Crawler self-propelling | |
| Engine | Model: | ZH1110/ZS1110/H20 |
| Type: | Single Cycling,4 stroke, water cooled | |
| Power | 14.7kw(20Hp) | |
| Speed | 2200rpm | |
| Overall Size | 2590x1130x2010mm(LxWxH) | |
| Weight: | 950kg | |
| Width of cutting table: | 1100mm | |
| Feeding Quantity: | 1.0kg/s | |
| Ground clearance: | 172 mm | |
| Thresher Drum: | Qty: | 2 |
| Main drum type | stripping belt | |
| Main drum size | 1397x725mm | |
| Theorectical operating speed | 1.6-2.8km/h | |
| Mud depth | ≦200mm | |
| Total loss | ≦2.5% | |
| Sundries | ≦1% | |
| Breakage | ≦0.3% | |
| Hourly production | 0.08-0.15ha/h | |
| Fuel consuspension | 12-20kg/ha | |
| Type of cutter | Reciprocating type | |
| Type of concave screen | grid type | |
| Fan | type | centrifugal |
| diameter | 250 | |
| quantity | 1 | |
| Crawler | specification | 80x32x280mm pitchxpitch numberxwidth |
| Transmission | mechanical | |
| Brake type | internal jaw | |
| Re-thresher type | axial flow spiked | |
| Gain collecting type | manual grain collecting | |
FAQ:
1. Do you have vedios to see how it work?
Yes. We have, and can show you if you need.
2. Can I buy a set as sample?
Yes. We can supply.
3. What's delivery time
Within 10-45 days after order
4. What's warranty terms
1 year after receipt of machine
5. What's the packing.
Nude packing. 2 sets in a standard 20" container. and 4 sets in a
40' foot container.
6. How to ship
We send by sea to the nearest ocean port to you.
7. Do you have operation manual and parts manual?
Yes. operation manual and parts manual will be supplied for each
machine.
